1.High-strength overhead guard the overhead guard is made of special-shaped steel pipe, with high strength and good cab sealing;
2.The aluminum plate-fin radiator with stronger heat dissipation performance and higher structural strength is adopted, independent oil radiator,
optimized heat dissipation channel, and double ventilation hole balance greatly improves the cooling efficiency, improves the reliability of heavy-duty operation, and ensures the engine Works reliably;
3.The optional three-way catalytic device reduces harmful emissions next to the low-emission engine; the sound insulation cotton is used to reduce noise, and the high exhaust system is used to reduce dust.
Model | FB10 | |
Rated Capacity | kg | 1000 |
Load Center Distance | mm | 500 |
Power Type | Lithium Battery | |
Wheel Base | mm | 1360 |
Wheel Number(Front/Rear) | 2×/2 | |
Tyre(Front) | 6.50-10-12PR | |
Tyre(Rear) | 5.00-8-8PR | |
Mast Tilting Angle,Front/Rear | 45455 | |
Free Lifting Height | mm | 140 |
Max.Lifting Height | mm | 3000 |
Max.Height After Lifting | mm | 4025 |
Overall Guard Height | mm | 2100 |
Fork Size:Length X Width X Thickness | mm | 1070×100×32 |
Overall Length(Fork Excluded) | mm | 2035 |
Overall Width | mm | 1090 |
Turning Radjus | mm | 1997 |
Lateral Fork Adjustment Max./Min | mm | 970/200 |
Self Weight | Kg | 2960 |
Battery Voltage /Capacity | V/Ah | 80/150 |
Battery Weight | Kg | 580 |
Driving Motor Power-60 Minutes | Kw | 8 |
Lifting Motor Power(S315%) | Kw | 10.0 |
Driving Motor Control Mode | Full AC | |
Lifting Motor Control Mode | Full AC | |
Service Brake/Parking Brake | Hydraulic /Mechanica |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
