1.Equipped with OPS or ORS seat and brake switch to prevent incorrect operation and secure the driver and the forklift from all sides;
2.The load-sensing steering system is adopted to further improve the working efficiency;
3.Improve the working environment of the main bearing and connecting rod bearing components,
prolong the service life of the engine, and reduce the noise of the engine.
Model | FG25 | ||
Rated load | kg | 2500 | |
Load center distance | mm | 500 | |
Lift Height | mm | 3000 | |
Free Iift height | mm | 240 | |
Fork size(L×WxT) | mm | 1070×122x40 | |
Mast tilt angle(FR/RR) | 45455 | ||
Min. tuming radius | mm | 2230 | |
Height of overhead guard | mm | 2070 | |
Maximum drawbar pull(Full load) | KN | 11.4 | |
Gradeabity | % | 18 | |
Overall ength(Without forks) | mm | 2580 | |
Overall width | mm | 1160 | |
Fork height at maximum lift | mm | 3944 | |
Mast height | mm | 1995 | |
Tires | Front wheel | 7.00-12-12PR | |
Rear wheel | 6.00-9-10PR | ||
Wheelbase | mm | 1600 | |
Self weigh | Kg | 3660 | |
Battery | Voltage/capacity | V/Ah | 12/80 |
Engine | Model | NISSAN | |
Number ofcylinders | 4 | ||
Displacement | L | 2.488 | |
Fuel tank capacty | L | 55 | |
Transmissions(FWD/RWD) | 1/1 Manual shift | ||
Tire type(FRV/RR) | Pneumatic |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
