1.You can take advantage by using the Telescopic Forklift while load and unload the truck/trailer from only one side, that will occupy half of yard loading space;
2.Shelves can tilt 111 degrees, making it easier and safer to handle unstacked goods;
3.Pilot valve control: enable all operating functions including in a joystick.
| Model | SFT50 | ||
| Rated Load | kg | 5000 | |
| Maximum Lifting Height | m | 7 | |
| Maximum Front Reach | m | 6.8 | |
| Overall Length (To Fork Carrier) | m | 6.08 | |
| Overall Width | m | 2.26 | |
| Overall Height | m | 2.54 | |
| Wheelbase | m | 3.3 | |
| Ground Clearance | m | 4 | |
| Turning Radius | m | 4 | |
| Weight | kg | 11000 | |
| Tires | 16/70-24 | ||
| Fork Size(L×W×T) | mm | 1200×125×45 | |
| Lifting | s | 7.2 | |
| Lowering | s | 5.5 | |
| Extension | s | 6.5 | |
| Retraction | s | 5.4 | |
| Engine | Manufacture | YUCHAI | |
| Model | YC4DK90-T304 | ||
| Displacement | L | 3.621 | |
| Rated Output/r.p.m. | Kw | 73.5 | |
| Rated Torque/r.p.m. | N.m | 400 | |
| Number Of Gears | F4/R4 | ||
| Maximum Speed | km/h | 34 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
