Telescopic Forklift

3.5 Ton -10 m Telescopic Forklift


Load capacity: 3.5 ton

Lifting height: 10500 mm

Tyre: 16/70-20

Fork length: 1220 mm

Engine: Yuchai
Description Warranty Info
Description

1.In the torsionally rigid heavy-duty frame, which can safely absorb the high payloads of the machines due to its closed design and large material thicknesses

2.With up to 9-functions on the joystick, you have the most important machine functions at your fingertips.

3.Our telehandlers are des igned to realize fast and high material handling.


ModelSFT35-10
Max. capacity3500 kg
Max. lifting height10.5 m
Max. outreach6.1 m
Overall length to carriage5.8 m
Length to face of forks7 m
Overall width2.2 m
Overall height2.55 m
Wheelbase3.15 m
Ground clearance0.35 m
Overall cab width0.84 m
Tilt-up angle12°
Tilt-down angle114°
External turning radius(over tyres)4.25 m
Unladen weight (with fork)9500 kg
Standard tires16/70 -20
Forks(length×width×section)1220×125×50 mm
Lifting10 s
Lowering7 s
Extension12 s
Retraction8.6 s
Crowd4.8s
Dump3.4 s
Engine brandYuchai
Engine normNational II
Max. fuel sulphur content5000 ppm
Engine modelYCD4M22T-105
Number of cylinders4
Capacity of cylinders4400 cm³
Engine power114 Hp / 85 kW
Max. torque / Engine rotation400Nm / 1400 rpm


With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail.

Warranty Info

Warranty Term

1. One year or 2000 working hours which occurs first.

2. 24 hours On-line service
