1.In the torsionally rigid heavy-duty frame, which can safely absorb the high payloads of the machines due to its closed design and large material thicknesses
2.With up to 9-functions on the joystick, you have the most important machine functions at your fingertips.
3.Our telehandlers are des igned to realize fast and high material handling.
| Model | SFT50-14 | SFT50-18 |
| Max. capacity | 5000 kg | 5000 kg |
| Max. lifting height | 13.8 m | 17.55 m |
| Max. outreach | 7 m | 11.2 m |
| Overall length to carriage | 6.4 m | 6.8 m |
| Length to face of forks | 7.62 m | 8 m |
| Overall width | 2.4 m | 2.4 m |
| Overall height | 2.55 m | 2.6 m |
| Wheelbase | 3.15 m | 3.45 m |
| Ground clearance | 0.38 m | 0.42 m |
| Overall cab width | 0.84m | 0.84 m |
| Tilt-up angle | 12° | 12° |
| Tilt-down angle | 114° | 114° |
| External turning radius(over tyres) | 4.1 m | 4.1 m |
| Unladen weight (with fork) | 13300 kg | 13700 kg |
| Standard tires | 16/70 -24 | 16/80 -24 |
| Forks(length×width×section) | 1220×125×50 mm | 1220×125×50 mm |
| Lifting | 18 s | 18 s |
| Lowering | 14.4 s | 14.4 s |
| Extension | 17.9 s | 17.9 s |
| Retraction | 16.5 s | 16.5 s |
| Crowd | 5.1 s | 5.1 s |
| Dump | 4 s | 4 s |
| Engine brand | Yuchai | Yuchai |
| Engine norm | National II | National II |
| Max. fuel sulphur content | 5000 ppm | 5000 ppm |
| Engine model | YCD4M22T-105 | YCD4M22T-105 |
| Number of cylinders | 4 | 4 |
| Capacity of cylinders | 4400 cm³ | 4400 cm³ |
| Engine power | 122 Hp / 91 kW | 122 Hp / 91 kW |
| Max. torque / Engine rotation | 400Nm / 1400 rpm | 400Nm / 1400 rpm |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
