1. With its powerful traction. The truck remains stable on rough roads, then the battery can be used for long time.
2. The use of separate motors to drive hydraulic gear pumps results in high power utilization, reduced system noise. Greathy improves thevehicle's reliability and service life of themachine.
3. Low noise, good bassing ability high mobility, using,warranty, repair convenience, no pollution.
| Model | FDS100 | ||
| Power Type | Diesel | ||
| Rated Capacity | kg | 10000 | |
| Load Centre | mm | 600 | |
| Lift Height | mm | 3600 | |
| Fork Size (L×W×T) | mm | 1520×175×85 | |
| Ground Clearance | mm | 160 | |
| Overall Dimension（L×W×H） | mm | 6250×2620×2960 | |
| Platform Width | mm | 1800 | |
| Platform Length | mm | 6250 | |
| Turning Radius | mm | 5650 | |
| Travel Speed | km/h | l/7 2/15 | |
| Lifting Speed | mm/s | 350 | |
| Tire | Front | 2×9.00-20-14PR | |
| Rear | 4×9.00-20-14PR | ||
| Wheelbase | mm | 3700 | |
| Weight | kg | 15600 | |
| Battery(Voltage/Capacity) | V/Ah | (12/80)×2 | |
| Engine | Model | CY6102BZG-B46 | |
| Manufacturer | CHAOCHAI | ||
| Rated output/r.p.m | kw | 84.6/2500 | |
| Rated torque/r.p.m | N·m | 430/1500-1700 | |
| No.of Cylinder | 6 | ||
| BorexStroke | mm | 102×118 | |
| Displacement | CC | 5785 | |
| Fuel Tank Capacity | L | 260 | |
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
