1. Supports data monitoring function, which can track the cargo status and forklift operation status in real time
2. Equipped with advanced maneuvering systems, such as electric drive and steering systems, the trucks are more flexible and can be easily steered and maneuvered in narrow spaces.
3. Battery operated, reducing environmental pollution and noise during operation, suitable for closed or sensitive working environments.
Model | FBZ20 | |
Rated Capacity | kg | 2000 |
Mast Lift Height | mm | 4300-10050 |
Mast Free Lift Height | mm | 1365-3635 |
Mast Closed Height | mm | 2265-4615 |
Mast Full Extended Height | mm | 5561-11313 |
Overall Length | mm | 2780 |
Ground Clearance | mm | 50 |
Overhead Guard Height | mm | 2270 |
Chassis Width Rear | mm | 1220 |
Chassis Width Front | mm | 980 |
Load Centre | mm | 600 |
Wheelbase | mm | 1735 |
Seat Height | mm | 1220 |
Mast Tilt Angle (F/R) | degree | 1/3 |
Travel Speed | km/h | 16 |
Lift Speed(Load/Unload) | m/s | 0.44/0.5 |
Front Tyre Size | mm | 412x174 |
Rear Tyre Size | mm | 457x150 |
Grade Ability(Load/Unload) | % | 18/20 |
Battery Voltage/Capacity | V/AH | 80/500 |
Weight Excluding Battery | kg | 5150 |
Weight Including Battery | kg | 6900 |
Traction Motor | kw | 19.5 |
Lifting Motor | kw | 15 |
Min Net Working Aisle Width | mm | 1800 |
Transfer Aisle Width | mm | 2700 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
