1.Adopting high-performance engine, strong power, low fuel consumption, simple structure, low noise, emissions comply with standards.
2.Precision instrument system can monitor parameters such as fuel, water temperature and air pressure.
3.Equipped with advanced safety systems, such as air-break brake, air-over-oil assisted braking system, etc., to enhance the safety of operation.
4.Special dustproof layer and sealed articulation point prolong the service life under heavy-duty working conditions, ensure stable work even under harsh environment, reduce the failure rate and increase the durability of the machine.
| Model | SC915 |
| Rated Capacity | 1500kg |
| Operating Weight | 3600kg |
| Bucket Capacity | 0.8m³ |
| Max. Dumping Height | 2900mm |
| Max. Dumping Distance | 1000mm |
| Overall Dimension（L×W×H） | 5325×1825×2700mm |
| Min. Turning Radius | 3750mm |
| Engine | Yunnei |
| Rated Power | 58KW |
| Torque Converter Type | Multitronic |
| Gearbox Model | 265 |
| Gear Shift | 2 forward, 2 reverse |
| Wheel Edge Reduction Type | Small round edge bridge |
| Max. Speed | 18km/h |
| Tire Size | 20.5--16 |
| Operating Type | Mechanical single joystick |
| Optional Operating Type | Pilot control |
| Optional Configuration | Air conditioner, rearview camera etc. |
| Optional Attachment | Quick hitch, fork, log grapple etc. |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
