1.Optional equipment, such as air conditioning, heating system, joystick, luxury or simple cab, special tires, extended arm and so on
2.The new cab has a spacious view, more operating space, with noise isolation and vibration damping, wide blades and large radiator fan can be optional air conditioning, radio and USB interface allows drivers to enjoy the work.
3.Equipped with suspension shock absorbing seat, single (double) handle joystick control system, electronic control shift, good vision and easy to operate control system, long time operation will not be too fatigue.
4.Adopting high-performance engine, strong power, low fuel consumption, simple structure, low noise, emissions comply with standards.
| Model | SC930 |
| Rated Capacity | 3000kg |
| Operating Weight | 8000kg |
| Bucket Capacity | 1.6m³ |
| Max. Lifting Height | 5050mm |
| Max. Dumping Height | 3800mm |
| Max. Dumping Distance | 1050mm |
| Overall Dimension（L×W×H） | 7000×2300×3060mm |
| Bucket Width | 2300mm |
| Engine | Weichai |
| Cylinder Number | 6 |
| Rated Power | 92KW |
| Torque Converter Type | Infinitely variable speed |
| Gearbox Model | 315 |
| Gear Shift | 4 forward, 4 reverse |
| Max. Speed | 36Km |
| Wheel Edge Reduction Type | 28-wheel-side reduction axle |
| Tyre Size | 17.5-25 |
| Wheelbase | 2770mm |
| Wheel Tread | 1690mm |
| Service Brake | Disc Brake |
| Parking Brake | Flexible shaft brake |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
