1.Cab with broad view, noise-isolation and vibration absorb-er meets all kinds of operation,which can bedismantled for Large space. Radio with MP3 function and speaker,thejoystick control system(Optional) ensure easy operation and more comfortable.
2.Four wheel double-line caliper disc braking system with a gas container in the back to guarantee a more safety and reliable operation.
3.Radio with USB key let drivers enjoy his working.
| Model | SC968 |
| Rated Capacity | 6000kg |
| Operating Weight | 19500kg |
| Bucket Capacity | 3-4m³ |
| Bucket Width | 3160mm |
| Overall Dimensions（L×W×H） | 8250×3210×3640mm |
| Max. Dumping Height | 3600mm |
| Max. Dumping Distance | 1300mm |
| Max. Climbing Gradient | 28° |
| Turning Angle | 35°± 1° |
| Wheelbase | 3100mm |
| Turning Radius | 7134mm |
| Engine | Weichai |
| Rated Power | 175KW/2200r/min |
| Max.Breakout Forth | 175kN |
| Max.Torque | 1000N.m |
| Lifting Time | ≤6.5s |
| Hydraulic Cylinder Time | ≤10.5s |
| Tire Size | 26.5-25 |
| Forward Gear I | 11.5km/h |
| Forward Gear II | 38km/h |
| Reserve Gear I | 16km/h |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
