1.Cab with broad view, noise-isolation and vibration absorb-er meets all kinds of operation,which can bedismantled for Large space. Radio with MP3 function and speaker,thejoystick control system(Optional) ensure easy operation and more comfortable.
2.Four wheel double-line caliper disc braking system with a gas container in the back to guarantee a more safety and reliable operation.
3.Radio with USB key let drivers enjoy his working.
| Model | SC978 |
| Rated Capacity | 7000kg |
| Operating Weight | 24300kg |
| Bucket Capacity | 4.2-4.6m³ |
| Bucket Width | 3300~3500 mm |
| Overall Dimensions（L×W×H） | 8600×3230×3800mm |
| Max. Dumping Height | 3460mm |
| Max. Dumping Distance | 1300mm |
| Max. Climbing Gradient | 30° |
| Turning Angle | 35°±1° |
| Wheelbase | 3380mm |
| Wheel Tread | 2280mm |
| Turning Radius | 7400mm |
| Engine | Weichai |
| Rated Power | 199KW/2200r/min |
| Max.Breakout Forth | 202kN |
| Max.Torque | 186kN |
| Lifting Time | ≤6.5s |
| Hydraulic Cylinder Time | ≤12s |
| Tire Size | 26.5-25 |
| Transmission | Beilian ZL80 fixed axis |
| Gear Shift | Forward 4/Reverse 4 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
