1.The new cab has a spacious view, more operating space, with noise isolation and vibration damping, wide blades and large radiator fan can be optional air conditioning, radio and USB interface allows drivers to enjoy the work.
2.Equipped with suspension shock absorbing seat, single (double) handle joystick control system, electronic control shift, good vision and easy to operate control system, long time operation will not be too fatigue.
3.Adopting high-performance engine, strong power, low fuel consumption, simple structure, low noise, emissions comply with standards.
4.Precision instrument system can monitor parameters such as fuel, water temperature and air pressure.
5.Equipped with advanced safety systems, such as air-break brake, air-over-oil assisted braking system, etc., to enhance the safety of operation.
| Model | SC988 |
| Rated Capacity | 8000kg |
| Operating Weight | 25300kg |
| Bucket Capacity | 5-5.5m³ |
| Bucket Width | 3520mm |
| Overall Dimensions（L×W×H） | 9100×3200×3640mm |
| Max. Dumping Height | 3550mm |
| Max. Dumping Distance | 1300mm |
| Max. Climbing Gradient | 28° |
| Turning Angle | 35°±1° |
| Wheelbase | 3350mm |
| Wheel Tread | 2470mm |
| Turning Radius | 7470mm |
| Engine | Weichai |
| Rated Power | 247Kw/2200r/min |
| Max.Breakout Forth | 175kN |
| Max.Torque | 1350N.m |
| Lifting Time | ≤6.5s |
| Hydraulic Cylinder Time | ≤10.5s |
| Tire Size | 26.5-25 |
| Transmission | Beilian ZL80 fixed axis |
| Gear Shift | Forward 4/Reverse 4 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
