1.Adopting large-displacement double-pump merging hydraulic system, with large cylinder power, fast arm lifting and faster loading speed.
2.Mutiple seletion of engine to meet different emission standard.
3.Multi-functional cab, combined instrumentation real-time display of vehicle operating status, can quickly identify fault information.
| Model | SC1000 |
| Rated Capacity | 10000kg |
| Operating Weight | 36000kg |
| Bucket Capacity | 6.2-6.3m³ |
| Overall Dimensions（L×W×H） | 11000×3300×3500mm |
| Max. Dumping Height | 3450mm |
| Max. Climbing Gradient | 28° |
| Turning Angle | 35°±1° |
| Wheelbase | 3780mm |
| Turning Radius | 7470mm |
| Engine | Weichai |
| Rated Power | 276Kw/2200r/min |
| Max.Breakout Forth | 175kN |
| Max.Torque | 1350N.m |
| Lifting Time | ≤6.5s |
| Hydraulic Cylinder Time | ≤10.5s |
| Tire Size | 29.5-25 |
| Transmission | Beilian ZL80 fixed axis |
| Gear Shift | Forward 4/Reverse 4 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
