1.It can replace different working devices, such as buckets, bulldozers, grapples, etc., to perform a variety of tasks, increasing the use value and scope of application of the equipment.
2.Optional equipment, such as air conditioning, heating system, joystick, luxury or simple cab, special tires, extended arm and so on
3.The new cab has a spacious view, more operating space, with noise isolation and vibration damping, wide blades and large radiator fan can be optional air conditioning, radio and USB interface allows drivers to enjoy the work.
| Model | SC910 |
| Rated Capacity | 1000kg |
| Operating Weight | 3000kg |
| Bucket Capacity | 0.8m³ |
| Max. Dumping Height | 2900mm |
| Max. Dumping Distance | 900mm |
| Overall Dimension（L×W×H） | 5600×1810×2750mm |
| Engine | Yunnei |
| Cylinder Number | 4 |
| Rated Power | 42 KW |
| Steering Type | Full-hydraulic, articulated |
| Torque Converter Type | Automatic, hydraulic converter |
| Gear Shift | 2 forward, 2 reverse |
| Max. Speed | 25 km/h |
| Tire Size | 20.5-16 |
| Service Brake | Oil drum brake on 4 wheels |
| Parking Brake | Hand operated drum brake |
| Operating Type | Mechanical single joystick |
| Optional Operating Type | Pilot control |
| Optional Configuration | Air conditioner, rearview camera etc. |
| Optional Attachment | Quick hitch, fork, log grapple etc. |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
