1.Provide a wide range of products from small to large, from basic to high-end, to meet different customer needs
2.It can be diversified and customized according to different working conditions, and a variety of accessories are optional, customize the most suitable model.
3.Adopting special structural design and high quality materials, thickened steel plate, enlarged hinge pin and hinge shaft to improve the carrying capacity, making the machine more powerful.
4.It can replace different working devices, such as buckets, bulldozers, grapples, etc., to perform a variety of tasks, increasing the use value and scope of application of the equipment.
| Model | SC920 |
| Rated Capacity | 2000kg |
| Operating Weight | 5000kg |
| Bucket Capacity | 1.2m³ |
| Max. Dumping Height | 3500mm |
| Max. Dumping Distance | 1000mm |
| Overall Dimension（L×W×H） | 5650×2000×2750mm |
| Min. Turning Radius | 3750mm |
| Engine | Yunnei |
| Rated Power | 76KW |
| Torque Converter Type | Infinitely variable speed |
| Gearbox Model | 265 |
| Gear Shift | 4 forward, 4 reverse |
| Wheel Edge Reduction Type | Wheelside reduction axle |
| Max. Speed | 36km/h |
| Tire Size | 16/70-20 |
| Wheelbase | 2330mm |
| Wheel Tread | 1580mm |
| Operating Type | Mechanical single joystick |
| Optional Operating Type | Pilot control |
| Optional Configuration | Air conditioner, rearview camera etc. |
| Optional Attachment | Quick hitch, fork, log grapple etc. |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
