1. Separated gearbox and torque converter with hydrodynamic transmission technology make high reliability and easy maintenance.
2. Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operate easy.
3. Single pump, split flow working hydraulic system makes lower consumption and excellent performance.
4. Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage.
5. Load sensing fully hydraulic steering system makes operation easy.
| Model | SC928 |
| Rated Capacity | 2800kg |
| Operating Weight | 7800kg |
| Bucket Capacity | 1.5m³ |
| Max. Lifting Height | 5050mm |
| Max. Dumping Height | 3800mm |
| Max. Dumping Distance | 1050mm |
| Overall Dimension（L×W×H） | 7000×2300×3060mm |
| Bucket Width | 2300mm |
| Engine | Weichai |
| Cylinder Number | 6 |
| Rated Power | 92KW |
| Torque Converter Type | Multitronic |
| Gearbox Model | 315 |
| Gear Shift | 4 forward, 4 reverse |
| Max. Speed | 36Km |
| Wheel Edge Reduction Type | 28 Wheelside reduction axle |
| Tyre Size | 17.5-25 |
| Wheelbase | 2750mm |
| Wheel Tread | 1650mm |
| Service Brake | Disc brake |
| Parking Brake | Soft shaft brake |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
