1. Standard with digging end side shift, wide field of vision, large digging range, greatly improve work efficiency.
2. Famous brand turbocharged engine, high efficiency, energy saving, low noise, strong power.
3. H-legs and A-legs are available, with beautiful appearance, high load capacity and ultra-high stability.
| Model | SC20-28 |
| Overall Dimension（L×W×H） | 6200*1960*2800mm |
| Wheel Base | 2550mm |
| Min. Ground Clearance | 290mm |
| Operating Weight | 5400Kg |
| Max. Speed | 28Km/h |
| Max. Climbing Gradient | 25° |
| Digging Parameters | |
| Turning Radius | 4500mm |
| Max. Digging Depth | 2600mm |
| Max. Digging Dumping Height | 2300mm |
| Bucket Width | 600mm |
| Backhoe Capacity | 0.2m3 |
| Max. Digging Height | 4300mm |
| Max. Digging Force | 28kN |
| Loading Parameters | |
| Max. Dumping Height | 3500mm |
| Max. Dumping Distance | 900mm |
| Bucket Width | 2100mm |
| Bucket Capacity | 1m³ |
| Max. Loading Lifting Height | 4300mm |
| Max. Breakout Force | 42kN |
| Engnie | Yunnei YN38GBZ |
| Rated Power | 76KW |
| Tire Size | 16/70-20 |
| Drive Type | Four-wheel drive |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
