1.Multi-functional operator console for easy operation of the entire vehicle.
2.The cab adopts a large area of glass, good lighting and wide field of vision, the driver is more comfortable to operate.
3.Fully hydraulic steering, power shift transmission, hydraulic manipulation of the working device.
| Model | SC30-25 |
| Overall Dimension（L×W×H） | 5654×2365×3764mm |
| Wheel Base | 2415mm |
| Min. Ground Clearance | 300mm |
| Operating Weight | 7600kg |
| Max. Gradient Capacity | 30° |
| Digging Parameters | |
| Backhoe Capacity | 0.3m³ |
| Max. Digging Depth | 4060mm |
| Max. Digging Radius | 5688mm |
| Max. Digging Dumping Height | 3820mm |
| Max.Digging Heigh | 5500±20mm |
| Loading Parameters | |
| Bucket Capacity | 1m³ |
| Max. Dumping Height | 2780mm |
| Max. Dumping Distance | 1112mm |
| Max. Breakout Force | 47KN |
| Engine | YUCHAI YC4A105Z-T20 |
| Rated Power | 75KW(100HP) |
| Tire Size | 16/70-20 |
| Drive Type | Four-wheel drive |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
