1. The use of an open hydraulic system makes the operation more stable, the response more agile, and the excavation control more accurate.
2. The hydraulic system adopts a high-efficiency gear single-pump system, and the main components of the pump, multi-way valve, and steering gear are all selected from well-known domestic companies.
3. The service brake and parking brake are wet brake, which has good braking effect, convenient parking brake adjustment, original imported components, reliable quality, and ensures driving safety.
| Model | BSC388-Ⅱ | |
| Form factor | mm | 6150×2350×3763 |
| Minimum ground clearance | mm | 300 |
| Total weight | kg | 8500 |
| Maximum speed | km/h | 22-35 |
| Maximum digging depth | mm | 4000/5200 |
| Dig the unloading height | mm | 4500/5300 |
| Maximum lifting height | mm | 6060/7200 |
| Digging dou Rong | m³ | 0.3 |
| Maximum unloading height | mm | 2742 |
| Maximum unloading distance | mm | 1062 |
| Rated Load | kg | 2500 |
| Bucket Roll | m³ | 1 |
| Engine model | Yuchai 4105 | |
| Rated power | kw | 85 |
| Gearbox | Front 2 Rear 2 | |
| Tire specifications | 14.-17.5/19.5-24 | |
| Service brakes | Air top caliper disc brake | |
| Drive type | Four-wheel drive |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
