1.The ultra-large area of tinted glass, low indoor noise level, independent heating and air conditioning system and spacious indoor space bring great comfort to the driver.
2.Optional special working devices such as breaker hammers can achieve multi-function.
3.The four-speed synchronous electro-hydraulic shift gearbox designed and manufactured specifically for excavators and loaders can quickly shift gears according to road condition
| Model | BSC388H-III | |
| Form factor | mm | 6500×2500×3800 |
| Wheelbase | mm | 2250 |
| Tread | mm | 2050 |
| Minimum ground clearance | mm | 400 |
| Total weight | kg | 9500 |
| Maximum speed | km/h | 38 |
| Maximum digging depth | mm | 4000/5300 |
| Dig the unloading height | mm | 3800/4450 |
| Maximum digging radius | mm | 5400/6500 |
| Maximum lifting height | mm | 5480/6100 |
| Digging dou Rong | m³ | 0.3 |
| Excavator swing angle | ° | 190 |
| Maximum unloading height | mm | 2500 |
| Maximum unloading distance | mm | 800 |
| Rated Load | kg | 2500 |
| Bucket Roll | m³ | 1.2 |
| Engine model | Yuchai 4105/4108 | |
| Rated power | kw | 75/85 |
| Bridge type | 100 steering drive axle | |
| Gearbox | 4 in front 4 in the rear | |
| Tire specifications | 16.9-28-14 | |
| Service brakes | Air top caliper disc brake | |
| Drive type | Four-wheel drive |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
