1. Provide a wide range of products from small to large, from basic to high-end, to meet different customer needs
2. Optional equipment, such as air conditioning, heating system, joystick, luxury or simple cab, special tires, extended arm and so on
3. The new cab has a spacious view, more operating space, with noise isolation and vibration damping, wide blades and large radiator fan can be optional air conditioning, radio and USB interface allows drivers to enjoy the work.
Model | SCS22 |
Max. Working Height | 2178 mm |
Max. Pin Height | 1890 mm |
Max. Dumping Height | 1395 mm |
The Highest Point Discharge Distance | 620 mm |
Bucket Swing Angle | 79° |
Bucket Unloading Angle | 36° |
Total Height | 1374mm |
The Height From The Ground | 90 mm |
Wheelbase | 705 mm |
Length(Without Bucket) | 1900 mm |
Total Width | 830mm |
Bucket Width | 835 mm |
Total Length(With Bucket) | 2400 mm |
Turning Radius | 1850 mm |
Engine Brand | Briggs & Stratton |
Engine Model | HONDA /GX690 |
Rated Power | 17.2KW |
Rotating Speed(Rpm) | 3000 |
Hydraulic Pressure | 20Mpa |
Load Weight | 240 Kg |
Bucket Capacity | 0.12m3 |
Max. Lifting Power | 850Kg |
Speed | 6Km/h |
Operating Weight | 1185kg |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
