1.Equipped with advanced safety systems, such as air-break brake, air-over-oil assisted braking system, etc., to enhance the safety of operation.
2.Adopt cleaner engine technology and optimized emission system to reduce the impact on the environment.
3.Adopting modularized design with long-life parts, easy to repair and reduce maintenance cost.
| Model | SCS75 | |
| Operating Load | Kg | 1050 |
| Max Speed | Km/H | 128 |
| Rated Flux | L/Min | 80 |
| Tire Model | 320X84 | |
| Self Weight Bucket | Kg | 4200 |
| Bucket Capacity | M³ | 0.5 |
| Overall Operating Height | mm | 3480 |
| Height To Top Of Cab | mm | 2150 |
| Overall Length With Bucket | mm | 2750 |
| Dumping Height | mm | 3500 |
| Dumping Height | mm | 2230 |
| Width | mm | 1782 |
| Bucket Width | mm | 1830 |
| Height To Bottom Of Level Bucket | mm | 2730 |
| Dumping Angle At Maximum Height | ° | 40 |
| Height To Bucket Hinge Pin | mm | 2900 |
| Dumping Reach | mm | 715 |
| Rollback Of Bucket On Ground | ° | 30 |
| Rollback Of Bucket At Full Height | ° | 104 |
| Wheelbase | mm | 1500 |
| Ground Clearance | mm | 200 |
| Angle Of Departure | ° | 20 |
| Front Turning Radius Without Bucket | mm | 1298 |
| Front Tuning Radius | mm | 2010 |
| Rear Tuning Radius | mm | 1714 |
| Rear Axle To Bumper | mm | 890 |
| Tread Width | mm | 1462 |
| Engine | Xinchai | |
| Rated Power | Kw | 55 |
| Fuel Tank Capacity | L | 90 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
