Secsun Machinery

Electric Loader

5-7 Ton Electric Loader


Rated capacity: 5-7 ton

Bucket capacity: 3-4.5 m³

Battery rated capacity: 456-608 Ah

Operating weight: 18500-25000 kg

Battery: Lithium
Description Warranty Info
Description

1. Precision instrument system can monitor parameters such as fuel, water temperature and air pressure.

2. Cabin design in safe and comfortable: big view, all of instruments set up in forward.Front light, rear light, turning light, horn, back up buzzing

3. Adopting modularized design with long-life parts, easy to repair and reduce maintenance cost.


ModelSC950EVSC970EV
Rated Load5000Kg7000Kg
Bucket Capacity3m³4.2-4.5m³
Operating Weight18500Kg25000Kg
Dumping Height3350mm3752mm
Dumping Reach1250mm1479mm
Wheel Base3350mm3700mm
Max. Traction170kN195KN
Max. Rising Power174kN210kN
Total Time9.7s9.7s
Lifting Time5.8s5.8s
Dumping Time3.5s3.5s
Max. Climbing Angle28°28°
Turning Angle40°40°
Forward Gear I/II18/36Km/h18/36km/h
Reserve Gear I18/36Km/h18/36km/h
Overall Dimensions8660mm×2960mm×3520mm9782×3007×3587mm
Tire Model23.5-2526.5-25
Battery Life4-5h5-7h
Charging Time60min(300Kw Charging Pile)60min(300Kw Charging Pile)
Power BatteryTypeLithium iron phosphateLithium battery
Rated Capacity618V/456Ah608Ah
Store Energy282kWh350kWh
Nominal Voltage618V576V


With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail.

Warranty Info

Warranty Term

1. One year or 2000 working hours which occurs first.

2. 24 hours On-line service
