1. High-power engine, strong power, large torque reserve, low fuel consumption, low noise, reliable performance
2. High-quality tires with special formula and enhanced rubber compound, strong grip
3. Self-developed and produced reinforced welded drive axle with compact and reasonable structure.
| Model | SC23T |
| Engine | Weichai |
| Rated Power | 178KW |
| Overall Length | 8350mm |
| Overall Width | 3210mm |
| Overall Height | 3690mm |
| Max. Dumping Height | 3250mm |
| Tire Model | 26.5-25 |
| Wheel Base | 3350mm |
| Wheel Tread | 2480mm |
| Dimensions Of Fork | 1500×250×120mm |
| Operating Weight | 23500kg |
| Rated Loading Capacity | 23t |
| Max. Climbing Gradient | 28° |
| Rated Speed | 2200r/min |
| Lifting Time | ≤6.8s |
| Hydraulic Cylinder Time | ≤12.55s |
| Forward Gear Ⅰ | 0-11.5km/h |
| Forward Gear II | 0-38km/h |
| Reverse Gear Ⅰ | 0-16km/h |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
