1. Superior shoveling and loading performance, equipped with a large bore lifting cylinder.
2. New cab, precise control, reduce labor intensity.
3. High power engine, strong power, large torque reserve, low fuel consumption, low noise, reliable performance.
| Model | SC40T |
| Engine | Weichai |
| Rated Power | 247KW |
| Overall Length | 11000mm |
| Overall Width | 3500mm |
| Overall Height | 4000mm |
| Max. Dumping Height | 3600mm |
| Tire Model | 29.5R29 |
| Wheel Base | 5444mm |
| Wheel Tread | 2660mm |
| Dimensions Of Fork | 1800×400×135 |
| Operating Weight | 45T |
| Rated Loading Capacity | 40T |
| Turning Angle | ±28° |
| Min.Ground Clearance | 400mm |
| Unloading Angle | 15.3° |
| Fuel Tank Capacity | 280L |
| Hydraulic Oil Tank Capacity | 280L |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
