1.Radiator: Powerful heat dissipation makes working efficiently
2.Press type: Easy to operate, adjust the output power of the engine
3.Rubber track: Built-in reinforcement steel wire, wear-resistant and durable
Model | SCE15 | |
Operating Weight | Kg | 1400 |
Engine Model | Kubota D722 | |
Rated Power | Kw | 10.4KW/2500rpm |
Bucket Capacity | m³ | 0.025 |
Bucket Width | mm | 385 |
Max Digging Force | Kn | 9 |
System Working Pressure | Mpa | 20 |
Swing Speed | rpm | 12-13 |
Traveling Speed | km/h | 2.1~3.2 |
Gradeability | ° | 58 |
Ground Pressure | Kpa | 23 |
Max. Digging Distance | mm | 3529 |
Max. Digging Depth | mm | 2017 |
Max. Digging Height | mm | 2955 |
Max. Dumping Height | mm | 2077 |
Overall Length | mm | 3329 |
Overall Width | mm | 990 |
Overall Height | mm | 2267 |
Min. Ground Clearance | mm | 153 |
Track Ground Length | mm | 1190 |
Track Width | mm | 200 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
