1. Clean and neatly assembled, easy maintenance
2. Integral casting process accessories. Casting parts are accurate in size, more robust and durable
3. Simple structure and compact design ,easy in installation and maintation.
| Model | SCE25 | |
| Operating Weight | Kg | 2350 |
| Engine Model | Kubota | |
| Rated Power | Kw | 14.2 |
| Bucket Capacity | m³ | 0.07 |
| Bucket Width | mm | 435 |
| Max Digging Force | Kn | 18 |
| System Working Pressure | Mpa | 21.5 |
| Swing Speed | rpm | 0-9 |
| Traveling Speed | km/h | 2.8 |
| Gradeability | ° | 35 |
| Ground Pressure | Kpa | 30 |
| Max. Digging Distance | mm | 4040 |
| Max. Digging Depth | mm | 2400 |
| Max. Digging Height | mm | 3700 |
| Max. Dumping Height | mm | 2440 |
| Min. Swing Radius | mm | 1610 |
| Overall Length | mm | 3555 |
| Overall Width | mm | 990/1300 |
| Overall Height | mm | 2290 |
| Min. Ground Clearance | mm | 150 |
| Track Ground Length | mm | 990 |
| Track Width | mm | 230 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
