1. the standard configuration bulldozer can be flat site, earth backfill, increase machine stability.
2. simple, small and flexible, easy to transport, can work in small venues, especially for orchards such as kiwifruit, vineyards, oranges, navel orange value, trenching, fertilization, weeding.
3. with mining, broken, clear hooks, drilling, earth multi-function, can quickly replace the accessories, machine utilization greatly improved.
| Model | SCE180 | |
| Operating Weight | Kg | 18000 |
| Engine Model | Cummins QSF3.8 | |
| Rated Power | Kw | 93KW/2200rpm |
| Bucket Capacity | m³ | 0.8 |
| Max Digging Force | Kn | 98 |
| Swing Speed | rpm | 0-12 |
| Traveling Speed | km/h | 2.8-4.2 |
| Gradeability | ° | 30° |
| Max. Digging Radius | mm | 8985 |
| Max. Digging Depth | mm | 5975 |
| Max. Digging Height | mm | 9430 |
| Max. Dumping Height | mm | 6960 |
| Min. Swing Radius | mm | 2725 |
| Overall Length | mm | 8540 |
| Overall Width | mm | 2720 |
| Overall Height | mm | 2920 |
| Axle Base | mm | 3200 |
| Wheel(track) Distance | mm | 2120 |
| Mini.Ground Clearance | mm | 480 |
| Track Width | mm | 600 |
| Undercarriage width | mm | 2720 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
