1.Radiator: Powerful heat dissipation makes working efficiently
2.Press type: Easy to operate, adjust the output power of the engine
3.Rubber track: Built-in reinforcement steel wire, wear-resistant and durable
| Model | SCE230 | |
| Operating Weight | Kg | 23000 |
| Engine Model | Cummins QSB7 | |
| Rated Power | Kw | 124KW/2050rpm |
| Bucket Capacity | m³ | 1.1 |
| Swing Speed | rpm | 11—13 |
| Traveling Speed | km/h | 3.8-4.2 |
| Gradeability | ° | 30° |
| Hydraulic system working pressure | Mpa | 34 |
| Hydraulic Pump | PNM | |
| Hydraulic Valve | Parker | |
| Swing Motor | Strong(Sunjin) | |
| Traveling Motor | Doosan | |
| Max. Digging Radius | mm | 9850 |
| Max. Digging Depth | mm | 6480 |
| Max. Digging Height | mm | 9410 |
| Max. Dumping Height | mm | 6730 |
| Min. Swing Radius | mm | 3555 |
| Overall Length | mm | 9565 |
| Overall Width | mm | 2990 |
| Overall Height | mm | 3000 |
| Track Width | mm | 600 |
| Track Height | mm | 950 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
