1. Simple structure and compact design ,easy in installation and maintation.
2. Give full consideration to reduce the working oil consumption, to obtain maximum efficiency in all kinds of work site operation.
3. Auger, grab, hydraulic hammer, narrow bucket can be installed on this excavator, efficient and wide-range use.
| Model | SCE600 | |
| Operating Weight | Kg | 53000 |
| Engine Model | Cummins QSM11 | |
| Rated Power | Kw | 298KW/2000rpm |
| Bucket Capacity | m³ | 3 |
| Max Digging Force | Kn | 325 |
| Swing Speed | rpm | 0-11 |
| Traveling Speed | km/h | 2.4-4.4 |
| Gradeability | ° | 35° |
| System Working Pressure | Mpa | 35 |
| Boom Length | mm | 6500 |
| Arm length | mm | 2550 |
| Max. Digging Radius | mm | 10726 |
| Max. Digging Depth | mm | 5756 |
| Max. Digging Height | mm | 11142 |
| Max. Dumping Height | mm | 7779 |
| Max. vertical digging depth | mm | 5064 |
| Overall Length | mm | 11690 |
| Overall Width | mm | 3360 |
| Overall Height | mm | 3810 |
| Mini.Ground Clearance | mm | 602 |
| Track Width | mm | 600 |
| Axle base(Track length on ground) | mm | 4021 |
| Track Gauge | mm | 2760 |
| Swing radius at tail | mm | 3760 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
