1.High-end configuration: The main pump, main valve, slewing motor, travel motor, oil cylinder, pilot operated valve and other components are all made of international famous brands to ensure the quality of the products.
2.Powerful and precise slewing control: improved vibration absorption characteristics ensure a more precise and smooth slewing stopping action; by increasing the torque reserve, the machine is given a more powerful slewing capacity.
3.Deployed outriggers relieve tire pressure, thereby boosting maximum lift capacity.
Model | SWE80 | |
Operating Weight | Kg | 8000 |
Engine Model | YC4DK85 | |
Rated Power | Kw | 55./2200 |
Bucket Capacity | m³ | 0.21 |
Swing Speed | rpm | 0-12 |
Gradeability | ° | 25 |
System Pressure | Mpa | 24 |
Max. Digging Depth | mm | 3900 |
Max. Digging Height | mm | 6380 |
Max. Dumping Height | mm | 4700 |
Max.Vertical Digging Depth | mm | 2700 |
Max.Vertical Digging Depth | mm | 6300 |
Min.Swing Radius | mm | 2400 |
Max.Dozer Blade Lifting Distance | mm | 370 |
Max.Dozer Blade Cutting Distance | mm | 110 |
Overall Length | mm | 6390 |
Overall Width | mm | 2175 |
Overall Height | mm | 2880 |
Cabin Height | mm | 2880 |
Axle Base | mm | 2400 |
Min. Ground Clearance | mm | 260 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
