1.Imported Korean hydraulic parts which ensures the stable quality.
2.Special design on separating engine and radiation space, using enhanced cooling fan to increase cooling efficiency.
3.Famous Cummins Engine, high efficiency, low repair cost.
4.Equipped with double fuel filter to guarantee fuel purity to protect engine.
| Model | SWE180 | |
| Operating Weight | Kg | 16000 |
| Engine Model | Cummins B5.9CS4-150C | |
| Rated Power | Kw | 111kw/2200RPM |
| Bucket Capacity | m³ | 0.8 |
| Max Digging Force | Kn | 100 |
| Swing Speed | rpm | 0-12 |
| Traveling Speed | km/h | 0-35 |
| Gradeability | ° | 25 |
| Max. Digging Radius | mm | 8363 |
| Max. Digging Depth | mm | 5350 |
| Max. Digging Height | mm | 8800 |
| Max. Dumping Height | mm | 6310 |
| Min.Swing Radius | mm | 2723 |
| Overall Length | mm | 8050 |
| Overall Width | mm | 2595 |
| Overall Height | mm | 3255 |
| Undercarriage width | mm | 2595 |
| Boom length | mm | 4800 |
| Arm length | mm | 2500 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
