1.Side-opening hood design for easy access and maintenance.
2.Adopting new large cab, easy and convenient to operate.
3.Powerful and precision-forged boom, buckets and bucket designs greatly increase the working range.
4.Rigid robotically welded construction ensures superior durability.
Model | SWE210 | |
Bucket Capacity | m³ | 1.1 |
Swing Speed | kw/h | 0-12 |
Gradeablity | ° | 25 |
Max.Bucket Digging Force | kn | 140 |
Max.Arm Digging Force | kn | 100 |
Engine Model | Cummins | |
Power/revolution speed | 153/2000 | |
Tire Model | 10-20 | |
System Pressure | 34 | |
Dimension Length*Width*Height | mm | 10006x2500x3515 |
Cabin Height | mm | 3216 |
Axle Base | mm | 2850 |
Wheel Distance | mm | 1920 |
Minimum ground clearance | mm | 380 |
Tail Swing Radius | mm | 2412 |
Boom Length | mm | 11.5 |
Arm length | mm | 5.5 |
Overall weight | kg | 6.3t |
Max.Digging Height | mm | 10329 |
Max.Dumping Height | mm | 7397 |
Max.Digging Depth | mm | 6052 |
Max.Vertical Digging Depth | mm | 5682 |
Max.Digging Radius | mm | 10282 |
Min. Swing Radius | mm | 3458 |
Max.Dozer Blade Lifting Distance | mm | 410 |
Max.Dozer Blade Cutting Distance | mm | 125 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
