Reach Truck

1.5 Ton Man Up Three-directions Tyer Reach Truck


Rated capacity: 1500 kg

Fork size: 45×125×1220 mm

Power type:Electric

Battery capacity: 48V/530Ah(Max. 900Ah)
Description Warranty Info
Description

1.Placing your feet on electric breaking switch, then you can takecontrol of the driving.

Only after the foot stepped on power switchcan operate vehicle, whereas the vehicle stop. So this designimproves the vehicle's safety performance.

2.It is endurable and has long battery lfe because of 48V high powerbattery.


Model
SFRB15
Rated Loadkg1500
Load centermm600
Front overhang distancemm384
Wheelbasemm1913
Front wheel sizemm350×200
Steering wheel sizemm400×160
Wheel tread:Frontmm1190
Height―Mast Loweredmm4480
Free lifting heightmm1500
Lifting heightmm7500
Max mast heightmm8400
Overhead guard heightmm2412
Fork Heightmm45
Overall heightmm3679
Overall lengthmm2448
Overall widthmm1474
Fork dimensionmm45×125×1220
Minimum Ground Clearancemm80
Drive motor powerkw8
Lifting motor powerkw12
Battery capacityV/Ah48V/530Ah(Max. 900Ah)
Drive control mode
AC

With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail.


Warranty Info

Warranty Term

1. One year or 2000 working hours which occurs first.

2. 24 hours On-line service
