1.This reduces fatigue and provides a more stable and secure driving experience.
2.With shock-absorbing wheels and advanced suspension systems, the ride-on vehicle ensures a comfortable and stable experience, even when navigating rough or uneven surfaces.
3.Equipped with various safety features such as anti-slip footrests, emergency stop functions, and stability controls, ensuring the safety of both the operator and others in the vicinity.
| Model | SRF12 | SRF15 | SRF20 | ||
| Power Type | Electric | Electric | Electric | ||
| Operation type | Seated Type | Seated Type | Seated Type | ||
| Capacity | kg | 1200 | 1500 | 2000 | |
| Load center | mm | 500 | 500 | 500 | |
| Front overhang | mm | 180 | 180 | 180 | |
| Wheelbase | mm | 1355 | 1355 | 1540 | |
| Total weight including the battery | kg | 1995 | 2180 | 2535 | |
| Mast height (fork lowering) | mm | 2120 | 2120 | 2120 | |
| Max Lifting Height | mm | 4500 | 4500 | 4500 | |
| Max.height | mm | 5485 | 5485 | 5485 | |
| Overhead guard height | mm | 2090 | 2090 | 2090 | |
| Fork height when gantry retracted | mm | 35 | 35 | 40 | |
| Mast/carriage tilt angle(front/rear) | α/β（°） | 3/5 | 3/5 | 3/5 | |
| Overall height（with forks) | mm | 2304 | 2304 | 2389 | |
| Overall length (without fork) | mm | 1689 | 1689 | 1874 | |
| Overall width | mm | 1090 | 1090 | 1090 | |
| Fork dimension | mm | 35/100/1070 | 35/100/1070 | 40/122/1070 | |
| Fork spread | mm | 210-705 | 210-705 | 244-705 | |
| Reach distance | mm | 500 | 500 | 600 | |
| Min ground clearance | 80 | 80 | 80 | ||
| Turning radius | mm | 1600 | 1600 | 1780 | |
| Driving motor | kw | 1.5 | 2.5 | 2.5 | |
| Lifting motor | kw | 3DC | 3DC | 3DC | |
| Battery type | Lead acid battery | Lead acid battery | Lead acid battery | ||
| Battery capacity | V/Ah | 24/280 | 24/280 | 24/280 | |
| Charger-Intelligent | V/A | 24/40 | 24/40 | 24/40 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
