1.The three-directional forklift is capable of moving in three directions: forward, sideways, and even diagonally.
2. This allows the forklift to navigate tight aisles and access palletized goods from multiple directions, optimizing space utilization in narrow aisles.
3.The three-way design allows operators to stack and retrieve pallets in both the forward and sideways directions, improving operational flexibility and speed.
| Model | SRF15 | |
| Operation type | Standing type | |
| Power type | Full-electric | |
| Capacity | KG | 1500 |
| Max Lifting Height | mm | 4000 |
| Load center | mm | 500 |
| Wheel type | Pu solid tire | |
| Fork dimensions | mm | 1070×125×45 |
| Fork spread | mm | 260-650 |
| Overall length including fork | mm | 4000/3100 |
| Overall width | mm | 1550 |
| Height--Mast Lowered | mm | 3120 |
| Maximum height when fork is lifting | mm | ≤5100 |
| Turning radius | mm | 2017 |
| The height of overhead guards | mm | 2280 |
| Min ground clearance | mm | 32 |
| Max travel speed | Km/h | 7/8 |
| Lifting speed | mm/s | 215/275 |
| Total weight | KG | ＞5000 |
| Driving Wheel | mm | 382×142 |
| Front wheel | mm | 145×100 |
| Battery capacity | V/Ah | 48/400 |
| Driving motor | Kw | 6.5（AC） |
| Lifting motor | Kw | 8.6（AC） |
| Steering control type | Electric | |
| Brake type | Electromagnetic |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
