1.The counterbalance design allows the stacker to handle heavier loads while maintaining stability, making it suitable for various load types.
2.The added weight at the rear enhances balance and control, especially when lifting loads to significant heights.
3.Equipped with a comfortable, ergonomic handle for ease of use and improved operator comfort during prolonged tasks.
| Model | SCES08 | SCES10 | SCES12 | SCES15 | |
| Drive type | electric | electric | electric | electric | |
| Driving Mode | Walking type | Walking type | Walking type | Walking type | |
| Rated load | kg | 800 | 1000 | 1200 | 1500 |
| Load Centre | mm | 450 | 450 | 450 | 500 |
| Wheelbase | mm | 1100 | 1200 | 1200 | 1400 |
| weight | kg | 1300 | 1400 | 1500 | 1650 |
| Tyre | Polyurethane wheel | Polyurethane wheel | Polyurethane wheel | Polyurethane wheel | |
| Drive wheel size | mm | 210×70 | 210×70 | 210×70 | 248×75 |
| Front wheel size | mm | 200×80 | 200×80 | 200×80 | 200×80 |
| Front wheelbase | mm | 830 | 830 | 830 | 830 |
| Overall vehicle length | mm | 2490 | 2590 | 2590 | 2940 |
| Overall vehicle width | mm | 960 | 960 | 960 | 960 |
| Fork size | mm | 920×100×35 | 920×100×35 | 920×100×35 | 1070×100×35 |
| Fork outer width | mm | 680 | 680 | 680 | 680 |
| Minimum ground clearance | mm | 40 | 40 | 40 | 60 |
| Drive motor power | kw | 0.75 | 0.75 | 0.75 | AC 1.5 |
| Lifting motor power | kw | DC 2.2 | DC 2.2 | DC 2.2 | DC 2.2 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
