1.Manufactured from high-strength materials to ensure the durability and load-carrying capacity of the unit.
2.The ability to operate in very confined spaces and even enter elevators fully loaded greatly increases its flexibility of use.
3.Relatively simple structure and relatively low repair and maintenance costs for hand pallet trucks.
| Model | HP20 | HP25 | HP30 | |
| Capacity | kg | 2000 | 2500 | 3000 |
| Lowered fork height | mm | 85 | 85 | 85 |
| Steering wheel | mm | φ180×50 | φ180×50 | φ180×50 |
| Max. lift height | mm | 200 | 200 | 200 |
| Total height | mm | 1214 | 1214 | 1214 |
| Overall length | mm | 1483 | 1533 | 1603 |
| Fork length | mm | 1150/1220 | 1150/1220 | 1150/1220 |
| Width Overall forks | mm | 550/685 | 550/685 | 550/685 |
| Ground clearance, center of wheel base | mm | 40 | 40 | 40 |
| Aisle width for Pallet 1000×1200 crossways | mm | 1683 | 1733 | 1803 |
| Aisle width for Pallet 800×1200 lengthways | mm | 1783 | 1783 | 1803 |
| Turning radius | mm | 1216 | 1266 | 1336 |
| Fork dimension | mm | 1150/1220×160×51 | 1150/1220×160×51 | 1150/1220×160×51 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
