1.Manufactured from high-strength materials to ensure the durability and load-carrying capacity of the unit.
2.The ability to operate in very confined spaces and even enter elevators fully loaded greatly increases its flexibility of use.
3.Relatively simple structure and relatively low repair and maintenance costs for hand pallet trucks.
| Model | HP15 | |
| Drive | Electric | |
| Operator type | Pedestrian | |
| Load capacity | kg | 1500 |
| Load center distance | mm | 600 |
| Load distance, centre of drive axle to fork | mm | 883/946 |
| Wheelbase | mm | 1202/1261 |
| Service weight | kg | 180 |
| Tyre type | Polyurethane | |
| Tyre size（front） | mm | φ210×70 |
| Tyre size（near） | mm | φ80×61 |
| Lift height | mm | 115 |
| Lowered height | mm | 80 |
| Overall length | mm | 1638 |
| Overall width | mm | 560(685) |
| Fork dimensions | mm | 50/150/1150 |
| Ground clearance, center of wheelbase | mm | 30 |
| Aisle width for pallets 1000*1200 crossways | mm | 2280 |
| Aisle width for pallets 800x1200 crossways | mm | 2150 |
| Turning radius | mm | 1475 |
| Travel speed（laden/unladen） | km/h | 4.5/5 |
| Service brake | Electromagnetic | |
| Drive motor rating S2 60 min | KW | 0.75 |
| Lift motor rating at S3 15% | KW | 0.84 |
| Battery voltageinominal capacity | V/Ah | 24/65 |
| Type of drive control | DC | |
| Steering design | Machanical |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
