1.The stand-on platform design allows operators to work comfortably while having easy access to controls, reducing fatigue during long shifts.
2.Intuitive controls allow for smooth operation, enabling quick learning and minimizing downtime for training.
3.Ideal for various tasks, including loading, unloading, and transporting goods, making it a valuable asset in any operation.
| Model | SFP20 | SFP25 | SFP30 | |
| Power Type | Electric | Electric | Electric | |
| Operation type | Stand Type | Stand Type | Stand Type | |
| Steering type | Electric steering | Electric steering | Electric steering | |
| Capacity | kg | 2000 | 2500 | 3000 |
| Load center | mm | 600 | 600 | 600 |
| Wheelbase | mm | 1380 | 1380 | 1380 |
| Max Lifting Height | mm | 205 | 205 | 205 |
| Fork lowered height | 85 | 85 | 85 | |
| Fork spread | mm | 685 | 685 | 685 |
| Overall length | mm | 1825/2240 | 1825/2240 | 1825/2240 |
| Overall width | mm | 760 | 760 | 760 |
| Fork dimension | mm | 55/175/1150 | 55/175/1150 | 55/175/1150 |
| Min.stacking.aisle.1000*1200pall | mm | 2220/2620 | 2220/2620 | 2220/2620 |
| Turning radius | mm | 970 | 970 | 970 |
| Driving motor | kw | 1.5 | 1.5 | 1.5 |
| Lifting motor | kw | 0.8DC | 0.8DC | 0.8DC |
| Battery type | Lead acid battery | Lead acid battery | Lead acid battery | |
| Battery capacity | V/Ah | 24/210 | 24/210 | 24/210 |
| Charger-Intelligent | V/A | 24/30 | 24/30 | 24/30 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
