1.Designed for ease of use, the walk-behind electric pallet truck allows operators to control movements effortlessly, making it suitable for all skill levels.
2.Its small footprint enables excellent maneuverability in tight spaces, ideal for crowded warehouses and retail environments.
3.The ergonomic handle and controls reduce operator fatigue, promoting comfort during extended use and increasing overall efficiency.
| Model | FEP15 | FEP20 | |
| Power unit | Electric | Electric | |
| Operation | Pedestrian | Pedestrian | |
| Rated traction weight | kg | 1500 | 2000.0 |
| Load centre | mm | 600 | 600 |
| Axle centre to fork face | mm | 944 | 944 |
| Wheel base | mm | 1243 | 1243 |
| Service weight | kg | 142 | 146 |
| Driving wheel size | mm | 210×70 | 210×70 |
| Bearing wheel size | mm | 80×60 | 80×60 |
| additional wheels（dimensions） | mm | 50×30 | 50×30 |
| Track width | mm | 400/535 | 400/535 |
| Lift | mm | 200 | 200 |
| Overall height(With handle) | mm | 740/1160 | 740/1160 |
| lowered hength | mm | 85 | 85 |
| Overall length | mm | 1603 | 1603 |
| Overall width | mm | 550/685 | 550/685 |
| Fork dimensions | mm | 50/150/1150 | 50/150/1150 |
| Width of forks | mm | 550/685 | 550/685 |
| Min.Ground clearance | mm | 35 | 35 |
| Min.Turning radius | mm | 1398 | 1398 |
| Service brake | Electromagnetic | Electromagnetic |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
