1.The reinforced PTO structure, large bearing capacity，meets the requirements of different operation.
2.Imported high strength powder metallurgic clutch plate,reliable transmission.
3.Vertical double oil cylinder high pressure lifter, large lifting force and good operation adaptability.
4.Optional for creeper gearbox , meets different working conditions.
| Model | STB1004 | STB1104 | STB1204 | |
| Type | 4×4 | 4×4 | 4×4 | |
| Overall Dimension(mm) | Length | 4080 | 4650 | 4130 |
| Width | 1750 | 2038 | 1720 | |
| High | 2650 | 2970 | 2650 | |
| Wheelbase(mm) | 2010 | 2449 | 2020 | |
| Front Wheel Tread(mm) | 1285 | 1610 | 1353 | |
| Rear Wheel Tread(mm) | 1340 | 1620-2020 | 1352 | |
| Min.Ground Clearance(mm) | 375 | 375 | 370 | |
| Min.Turning Radius(m) | One side brake | 3.8 | 4.8±0.2 | 4.8±0.2 |
| One side not brake | 4.3 | 5.5±0.2 | 5.5±0.2 | |
| Min.Using Mass(kg) | 3030 | 4249 | 4525 | |
| Gear Box | F12/R12 | F16/R8 | F12/R12 | |
| Speed(km/h) | Going | 0.44-33.34 | 1.58-33.69 | 0.49-37.06 |
| Retread | 0.59-10.31 | 2.41-34.67 | 4.72-13.83 | |
| Engine | Model | 4C6-10035 | LR6M5U22/0810E | 4C6-120C32 |
| Rated Power(kw) | 73.5 | 81 | 88.3 | |
| Rated Speed(r/min) | 2400 | 2200 | 2200 | |
| Tyre Type | Front Tyre | 9.5-24 | 13.9-24 | 9.5-24 |
| Rear Tyre | 14.9-30 | 16.9-34 | 14.9-30 | |
| Steering System Type | All Hydraulic front Wheel Steering | All Hydraulic front Wheel Steering | All Hydraulic front Wheel Steering | |
| Max.Lift-off Weight(KN) | 17.7 | 19.5 | ≥19.5 | |
| PTO Speed(r/min) | 760/1000(540/1000 or 540/760) | 760/1000(540/1000 or 540/760) | 540/1000 | |
| PTO Power(kw) | 62.5 | 68.9 | 71.2 | |
| Roots in Control Mode | Height Adjustment,Floating Control | Height Adjustment,Floating Control | Height Adjustment,Floating Control | |
| Max.Traction(KN) | 23.2 | 25.7 | 24.4 | |
| Counterweight Quality(kg) | F110/R200 | F110/R200 | F110/R200 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
