1.Branded control system with several automatic protection systems to provide a higher level of functional safety.
2.EPS is easy and flexible to operate and improves the stability of high speed driving.
3.AC drive system with high torque and high gradeability ensures smooth operation on uneven roads and slopes.
| Model | SCTB06 | ||
| Power Type | ELECTRIC | ||
| Rated traction weight | kg | 600 | |
| Max.drawbar pull | N | 6500 | |
| Rated drawbar pull | N | 1600 | |
| Max.travel speed | Loaded | km/h | 9.5 |
| Unloaded | km/h | 10.5 | |
| Overall length | mm | 1966 | |
| Overall width | mm | 1010 | |
| Overall height | mm | 1300 | |
| Wheelbase | mm | 1100 | |
| Min.turning radius | mm | 1850 | |
| Tread rear | mm | 820 | |
| Min.ground clearance | mm | 60 | |
| Tire | solid tires | ||
| Tire size | Front | 4.00-8 | |
| Rear axle | 4.00-8 | ||
| Truck weight | kg | 1150 | |
| Drive motor | kW | 6 | |
| Battery | DIN | ||
| Battery Capacity | V/AH | 48/275 | |
| Battery weight | kg | 540 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
