1.Adopt full hydraulic electronically controlled gearbox, full hydraulic steering and pilot technology to make the whole machine more flexible;
2.Equipped with double-axle four-wheel drive, large traction, safer and more stable;
3.The turning radius of the articulated frame is small.
| Model | STR35 | |
| Rated Capacity | kg | 3500 |
| Mast width | mm | 160 |
| Max.Gradeability (No load/Full load) | % | <35° |
| Frame articulation | mm | Front200 Rear250 |
| Weight | kg | 4400 |
| Mast Tilt Angle(F/R) | Deg | 12° |
| Dimension | mm | 3700*1800*2450 |
| Tires | mm | 20.5/70-16 |
| Turning radius (outside tires) | mm | 3600 |
| Lift Height | mm | 3000 |
| Fork length (standard) | mm | 1220 |
| Ground Clearance（Bottom of mast） | mm | 240 |
| Mast Lowered Height | mm | 2240 |
| Engine | Yunnei490 | |
| Rated output/r.p.m. | kw | 58/2200-2400 |
| Rated torque/r.p.m. | N·m | 220-450/1500-1800 |
| No.of Cylinder | 4 | |
| No.of Cylinder | mm | 102x115 |
| Displacement | L | 3.76 |
| Drive Model | 4WD | |
| Gearbox | 265 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
