1. Adopting modularized design with long-life parts, easy to repair and reduce maintenance cost.
2. It can be diversified and customized according to different working conditions, and a variety of accessories are optional, customize the most suitable model.
3. Centre monitor: fuel oil level and temperature gauge, water temperature gauge, oil pressure, chronometer, indicator light, warning lamp and so on.
Model | SC915-T |
Rated Load | 1500kg |
Engnie | Yunnei YN25GB |
Rated Power | 37KW |
Overall Length | 5800mm |
Overall Width | 1800mm |
Overall Height | 2680mm |
Max. Discharge height | 4500mm |
Min. Discharge height | 3500mm |
Bucket Capacity | 0.65 m³ |
Bucket Type | Heavy-duty bolt on teeth |
Max. Load | 1500kg |
Steering System | Articulated hydraulic steering |
Driving System | Four wheel drive |
Service Brake | Four wheel disc brake |
Parking Brake | Disc brake |
Tire Model | 20.5/70-16 |
Wheel base | 2500mm |
Wheel Track | 1500mm |
System pressure | 16Mpa |
Weight | 4200KG |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
