1. Dual Accelerator Control Model: manual operated + foot operated, easy to operate
2. Cabin design in safe and comfortable: big view, all of instruments set up in forward.Front light, rear light, turning light, horn, back up buzzing
3. Centre monitor: fuel oil level and temperature gauge, water temperature gauge, oil pressure, chronometer, indicator light, warning lamp and so on.
| Model | SC940-T |
| Rated Load | 4000kg |
| Engnie | WEICHAI |
| Rated Power | 129KW |
| Overall Length | 7800mm |
| Overall Width | 3230mm |
| Overall Height | 2300mm |
| Max. Discharge height | 5400mm |
| Min. Discharge height | 4000mm |
| Bucket Capacity | 2m³ |
| Bucket Type | Heavy-duty teeth |
| Max. Load | 4000kg |
| Steering System | Articulated hydraulic steering |
| Driving System | Four wheel drive |
| Service Brake | Four wheel disc brake |
| Parking Brake | Disc brake |
| Tire Model | G2 pattern 20.5-25 Tyre G2 |
| Wheel base | 2845mm |
| Wheel Track | 1825mm |
| System pressure | 19Mpa |
| Weight | 10000KG |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
