1. Adopts thickened wear-resistant tyres for longer service life.
2. The headlights are made of LED, which makes the vision clearer at night and increases work efficiency.
3. Thickened cylinder with good lifting performance and durability.
| Model | SC13 | ||
| Rated Load | kg | 200 | |
| Bucket Capacity | m³ | 0.13 | |
| Max. Lift Weight | kg | 330 | |
| Overall Dimensions | mm | 2110×1050×1345 | |
| Working Speed | km/h | 0-5 | |
| Rated Pressure | Mpa | 17 | |
| Lifting Time | S | 4.2 | |
| Descent Time | S | 3.1 | |
| Dumping Time | S | 1.5 | |
| Climbing Ability | % | 30 | |
| Working Weight | kg | 690 | 700 |
| Engine Brand | Briggs&Stratton 25T2 | Rato R420 | |
| Engine Type | Single-cylinder air-cooled petrol engine | ||
| Output Power | 13.5HP/3600rpm | 15HP/3600rpm | |
| Fuel Consumption | L/h | ≤3.8 | ≤4.2 |
| Starting Method | Electric start | ||
| Fuel Tank Capacity | L | 6.6 | 6.7 |
| Engine Oil Capacity | L | 1.1 | |
| Hydraulic Tank Capacity | L | 20 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
