1. Simple operation, modern model adopts electric drive, which makes the lifting and lowering process more stable and easy to control.
2. Relatively simple structure and low maintenance cost. Parts are easy to replace, which helps to reduce maintenance costs in long-term use.
3. Suitable for indoor and outdoor use, widely used in building construction, maintenance, warehousing and logistics and other fields.
| Model | SCPV0405 | SCPV0507 | SCPV0607 |
| Max.platform Height | 3600 mm | 4800 mm | 6000 mm |
| Max.machine Height | 4700 mm | 5900 mm | 7100 mm |
| Overall Length | 1360 mm | 1360 mm | 1360 mm |
| Overall Width | 760 mm | 760 mm | 760 mm |
| Overall Height | 1700 mm | 1980 mm | 1980 mm |
| Height of guardrail | 1100 mm | 1100 mm | 1100 mm |
| Platform length | 1320mm×500 mm | 1320mm×500 mm | 1320mm×500 mm |
| Platform width | 745 mm | 745 mm | 745 mm |
| Support foot expansion size | 15mm×65mm | 15mm×65mm | 15mm×65mm |
| Max load | 200 kg | 200 kg | 200 kg |
| Minimum turning radius | 1500mm | 1500mm | 1500mm |
| Travel speed | 0Km/h-4Km/h | 0Km/h-4Km/h | 0Km/h-4Km/h |
| Max Climb Capability | 5°-8° | 5°-8° | 5°-8° |
| Tyre size | Φ305mm×100mm | Φ305mm×100mm | Φ305mm×100mm |
| Drive motor | 24V/0.5Kw | 24V/0.5Kw | 24V/0.5Kw |
| Lifting Motor | 24V/1.2Kw | 24V/1.2Kw | 24V/1.2Kw |
| DC model Battery voltage/capacity | 2×12V/108Ah | 2×12V/108Ah | 2×12V/108Ah |
| DC model Charger | 24V/15A | 24V/15A | 24V/15A |
| Overall Net Weight | 810kg | 980kg | 1180kg |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
