Secsun Machinery

Mast Lift

Self-propelled Order Picker-SCPV0608


Model: SCPV0608

Loading Capacity: 159 kg

Machine Height maximum:8 m

Platform height maximum:6 m
Description Warranty Info
Description

1.The extension platform can be quickly deployed to the operating point

2.The minimum turning radius (inner wheel 0m) and compact design are convenient for working in small spaces

3.25% gradeability can climb the slope smoothly

4.Automatic fault code display for easy maintenance


ModelSCPV0608
Max. Working Height8.0m
Max. Platform Height6.0m
Loading Capacity159kg
Ext. Platform Capacity114kg
Overall dimensions(L×W×H)1.36m×0.82m×1.98m
Platform Dimension1.3×0.7×1.1m
Ext. Platform Length0.51m
Ground Clearance-stowed0.1m
Ground Clearance-raised0.023m
Wheelbase1.04m
Inner Turning Radius0
Outer Turning Radius1.4m
Lifting Motor24V DC/1.3KW
Drive Motor2X24V DC/0.5KW
Drive Speed-stowed4km/h
Drive Speed-raised1.1km/h
Up/Down Speed52/53 sec
Gradeability25%
 Max. Working Angle
Battery2×12V/100Ah
Charger24V/15A
TireΦ305×100mm
Weight1060kg


With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail.


Warranty Info

Warranty Term

1. One year or 2000 working hours which occurs first.

2. 24 hours On-line service
