1. Hydraulic double drum drive, infinitely variable speed, flexible operation
2. Electronic control vibration with great exciting force and high compaction performance
3. Electronic controlled hydraulic front drum steering with easy operation and small turning radius
4. Automatic controlled backward brake system ensures safe operation
| Model | SCC06 | ||
| Operating weight | kg | 640 | |
| Overall width | mm | 700 | |
| Overall length (with armrests flat) | mm | 2350 | |
| Full height (armrest standing up) | mm | 1690 | |
| Packing size | mm | 1480x810x1130 | |
| Wheel Width | mm | 650 | |
| Wheel Diameter | mm | 380 | |
| Starting | electric start | ||
| Engine Brand | HONDA | Changchai/KIPOR | |
| Engine Model | GX390 | 186F | |
| Engine Type | Petrol 4-stroke | Diesel four-stroke | |
| Output power | hp/kw | 13/9.7 | 9/6.6 |
| Speed | rpm | 3600 | 3600 |
| Electrical equipment | V | 12 | |
| Speed | km/h | 0-5 | |
| Climbing ability | % | 30 | |
| Vibration frequency | hz | 55 | |
| Vibration amplitude | mm | 0.5 | |
| Excitation force | kn | 30 | |
| Fuel capacity | L | 6.5 | 3.5 |
| Hydraulic tank capacity | 25 | ||
| Water tank capacity | L | 40 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
